MSI MPG B550I GAMING EDGE MAX AM4 Mini-ITX Motherboard
  • MSI MPG B550I GAMING EDGE MAX AM4 Mini-ITX Motherboard
  • MSI MPG B550I GAMING EDGE MAX AM4 Mini-ITX Motherboard
  • MSI MPG B550I GAMING EDGE MAX AM4 Mini-ITX Motherboard
Product Page After Image | AC Deal

MSI MPG B550I GAMING EDGE MAX AM4 Mini-ITX Motherboard

Price To be announced
Status Up Coming
Product Code 17856
Brand MSI

Key Features

  • Model: MPG B550I GAMING EDGE MAX
  • Supports Ryzen 5000 & 3000 Series and Ryzen 4000 G-Series processors
  • Supports DDR4, up to 4600(OC) MHz
  • 8+2+1 Digital Power Design
  • Premium Thermal Solution
  • View More Info
Up Coming

Specification

Basic Information
Supported CPUSupports AMD Ryzen 5000 & 3000 Series desktop processors (not compatible with AMD Ryzen 5 3400G & Ryzen 3 3200G) and AMD Ryzen 4000 G-Series desktop processors
ChipsetAMD B550 Chipset
Form FactorMini-ITX Form Factor
6.7 in. x 6.7 in. (17.0 cm x 17.0 cm)
Expansion Slots
PCI1x PCIe 4.0 / 3.0 x16 slot
M.2 Socket2x M.2 slots [Key M]
M2 1 slot [from AMD Processor]
Supports PCIe 4.0/3.0 x4
Supports SATA 6Gb/s
Supports 2260/ 2280 storage devices
M2_2 slot [from AMD B550 chipset]
Supports PCIe 3.0x4
Supports 2280 storage devices
Memory
TypeDDR4
Slots2 x memory slots
Supported MemorySupports DDR4 1866/ 2133/ 2400/ 2667 MHz by JEDEC
Supports DDR4 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3600/ 3733/ 3866/ 4000/ 4133/ 4266/ 4400/ 4466/ 4533 / 4600+ MHz by A-XMP OC MODE
1DPC 1R max speed 4600 MHZ
1DPC 2R max speed 4000 MHZ
Dual channel memory architecture
Supports non-ECC UDIMM memory
Supports un-buffered memory
Maximum Memory64GB
Graphics
Graphics1x HDMI 2.1 port, supports a maximum resolution of 4096 x 2160 @60Hz
Max Shared Memory2048 MB
Connector & Ports
HDMI1x HDMI 2.1 port, supports a maximum resolution of 4096 x 2160 @60Hz
USB (s)AMD B550 Chipset
3x USB 3.2 Gen 1 5Gbps ports [1 Type-C internal connector, and 2 ports are available through the internal USB 3.2 Gen 1 5Gbps connector]
4x USB 2.0 ports [2 Type-A ports on the back panel, 2 ports through the internal USB 2.0 connector]
AMD Processor
2x USB 3.2 Gen 2 10Gbps ports [1 Type-C port and 1 Type-A port] on the back panel
2x USB 3.2 Gen 1 5Gbps Type-A ports on the back panel
LAN Port (s)1x Realtek RTL8125B 2.5Gbps LAN controller
Wireless Communication moduleIntel AX200
The Wireless module is pre-installed in the M.2 [Key-E] slot
Supports MU-MIMO TX/RX, 2.4GHz / 5GHz [160MHz] up to 2.4Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax
Supports Bluetooth 5.1
Supported StorageAMD B550 Chipset
4x SATA 6Gb/s ports
2x M.2 slots [Key M]
M2 1 slot [from AMD Processor]
Supports PCIe 4.0/3.0 x4 1
Supports SATA 6Gb/s
Supports 2260/ 2280 storage devices
M2_2 slot [from AMD B550 chipset]
Supports PCIe 3.0x4
Supports 2280 storage devices
AudioRealtek ALC1200 Codec
7.1-Channel High Definition Audio
Supports S/PDIF output
Internal I/O Ports1x 24-pin ATX main power connector
1x 8-pin ATX 12V power connector
4x SATA 6Gb/s connectors
2x M.2 slots [M-Key]
1x USB 3.2 Gen 1 5Gbps Type-C port
1x USB 3.2 Gen 1 5Gbps connector [supports additional 2 USB 3.2 Gen 1 5Gbps ports]
1x USB 2.0 connector [supports additional 2 USB 2.0 ports]
1x 4-pin CPU fan connector
1x 4-pin water-pump fan connector
1x 4-pin system fan connector
1x Front panel audio connector
2x System panel connectors
1x 3-pin RAINBOW LED connector
1x Clear CMOS jumper
4x EZ Debug LED
TPM (Trusted Platform Module )N/A
Warranty Information
Manufacturing Warranty03 Years Warranty

Description

MSI MPG B550I GAMING EDGE MAX AM4 Mini-ITX Motherboard

MSI MPG B550I GAMING EDGE MAX AM4 Mini-ITX Motherboard supports AMD Ryzen 5000 & 3000 Series desktop processors and AMD Ryzen 4000 G-Series desktop processors. It supports DDR4 Memory, up to 4600(OC) MHz. it features an Extended Heatsink Design. Leading heatsink design, extended for maximum cooling and performance. Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs. Strengthened built-in M.2 thermal solution keeps M.2 SSDs safe while preventing throttling, making them run faster. With premium layout and digital power design to support more cores and provide better performance. It comes with 2oz Thickened Copper PCB: An enhanced PCB design improves heat dissipation and performance reliability. it has Audio Boost that rewards your ears with studio-grade sound quality. It features Dragon Center - A brand new software that integrates all MSI exclusive tools with a user-friendly user interface.

What is the price of MSI MPG B550I GAMING EDGE MAX Motherboard in Bangladesh?

The latest price of MSI MPG B550I GAMING EDGE MAX Motherboard in Bangladesh is 0৳. You can buy the MSI MPG B550I GAMING EDGE MAX Motherboard at best price from our website or visit any of our showrooms.

Questions (1)

Have question about this product? Get specific details about this product from expert.

Fokrul Islam on 22 Jan 2022

Q: will this processor support Ryzen 5 1600?

A: Sorry Sir, MSI MPG B550I GAMING EDGE MAX AM4 Mini-ITX Motherboard will not be compatible with Ryzen 5 1600.

By Star Tech Support 22 Jan 2022
