Gigabyte X299 Ultra Durable Motherboard

Gigabyte X299 Ultra Durable Motherboard
  • Gigabyte X299 Ultra Durable Motherboard
  • Gigabyte X299 Ultra Durable Motherboard
  • Gigabyte X299 Ultra Durable Motherboard
0 Customer Review
  • Brand: GIGABYTE
  • Product Code: Gigabyte X299 UD4
  • Availability: In Stock

Highlights

  • Supports Intel® Core™ X-series Processor Family
  • DDR4, 8 DIMMs
  • Intel® Optane™ Memory Ready
  • Intel® VROC ready
  • View More Info
Regular Price: 25,200৳
24,000৳
Special Price

Specification:

Motherboard
ChipsetIntel® X299 Express Chipset
Supported ProcessorsSupport for Intel® Core™ X series processors in the LGA2066 package
L3 cache varies with CPU
Max Memory8 x DDR4 DIMM sockets supporting up to 128 GB of system memory.
* Support for up to 512 GB of system memory when using Registered DIMMs.
* Supported when using a 44-lane or 28-lane CPU (6-core or above).
4 x DDR4 DIMM sockets supporting up to 64 GB of system memory.
* Supported when using a 16-lane CPU (4-core).
4 channel memory architecture.
* Supported when using a 44-lane or 28-lane CPU (6-core or above).
Dual channel memory architecture.
Supported when using a 16-lane CPU (4-core).
Support for DDR4 4333(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666(O.C.) / 2400 / 2133 MHz memory modules
Support for non-ECC Un-buffered DIMM memory modules
Support for Registered DIMM 1Rx8/2Rx8/1Rx4/2Rx4 memory modules (operate in non-ECC mode)
Support for Extreme Memory Profile (XMP) memory modules
Onboard VideoIntegrated Graphics Processor-Intel® HD Graphics support:
1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
* Support for DisplayPort 1.2 version.
1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz
* Support for HDMI 1.4 version.
Maximum shared memory of 1 GB
Onboard AudioRealtek® ALC1220 codec
High Definition Audio
2/4/5.1/7.1-channel
Support for S/PDIF Out
Peripheral interfacesChipset:
1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support) (M2Q_32G)
1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe x4/x2 SSD support) (M2P_32G)
8 x SATA 6Gb/s connectors
Support for RAID 0, RAID 1, RAID 5, and RAID 10
* Refer to "1-9 Internal Connectors," for the installation notices for the M.2 and SATA connectors.
Intel® Optane™ Memory Ready
Intel® VROC ready
Multi-Graphics Technology
Support for NVIDIA® Quad-GPU SLI™ and 3-Way (with 44-lane CPU) / 2-Way (with 44 & 28-lane CPU) NVIDIA® SLI™ technologies
Support for AMD Quad-GPU CrossFire™ and 3-Way (with 44-lane CPU) / 2-Way AMD CrossFire™ technologies
Onboard LANIntel® GbE LAN chip (10/100/1000 Mbit)
Warranty3 Years

Description :

Gigabyte X299 Ultra Durable Motherboard

  • Supports Intel® Core™ X-series Processor Family
  • Quad Channel Non-ECC Unbuffered DDR4, 8 DIMMs
  • Intel® Optane™ Memory Ready
  • Intel® VROC ready
  • ASMedia 3142 USB 3.1 Gen 2 with USB Type-A
  • 3-Way Graphics Support
  • Server-Class Digital Power Design
  • ALC1220 120dB SNR HD Audio with Smart Headphone AMP and WIMA audio capacitor
  • RGB FUSION support Digital LED and RGBW Light Strips
  • Smart Fan 5 features Multiple Temperature Sensors and Hybrid Fan Headers with FAN STOP
  • Dual Ultra-Fast M.2 with PCIe Gen3 x4 interface
  • NVMe PCIe Gen3 x4 U.2 support by optional adaptor
  • Intel GbE LAN Gaming Network with cFosSpeed Internet Accelerator Software
  • Anti-Sulfur Resistor Design
  • Ultra Durable™ 25KV ESD and 15KV Surge LAN Protection
  • Lightning-Fast Intel® Thunderbolt™ 3 AIC Support
  • GIGABYTE UEFI DualBIOS™
  • APP Center Including EasyTune™ and Cloud Station™ Utilities
03 years warranty
