Gigabyte GA-B250M-HD3 Motherboard

Gigabyte GA-B250M-HD3 Motherboard
  • Gigabyte GA-B250M-HD3 Motherboard
  • Gigabyte GA-B250M-HD3 Motherboard
  • Gigabyte GA-B250M-HD3 Motherboard
0 Customer Review
  • Brand: GIGABYTE
  • Product Code: GIGABYTE GA-B250M-HD3
  • Availability: In Stock

Highlights

  • Intel® B250 Express Chipset
  • Supports 7th/ 6th Generation Intel® Core™ Processors
  • 2 x DDR4 DIMM
  • 1 x PCI Express x16 slot
  • View More Info
Regular Price: 7,590৳
7,150৳
Special Price

Specification:

Motherboard
ChipsetIntel® B250 Express Chipset
Supported ProcessorsSupport for 7th and 6th generation Intel® Core™ i7 processors/ Intel® Core™ i5 processors/Intel® Core™ i3 processors/ Intel® Pentium® processors/Intel® Celeron® processors in the LGA1151 package
L3 cache varies with CPU
Max Memory2 x DDR4 DIMM sockets supporting up to 32 GB of system memory
* Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.
Dual channel memory architecture
Support for DDR4 2400* / 2133 MHz memory modules
* To support 2400 MHz or XMP memory, you must install a 7th generation processor.
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
* To support 2400 MHz or XMP memory, you must install a 7th generation processor.
Onboard VideoIntegrated Graphics Processor-Intel® HD Graphics support:
1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
* The DVI-D port does not support D-Sub connection by adapter.
1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz
* Support for HDMI 1.4 version.
Support for up to 3 displays at the same time
Maximum shared memory of 1 GB
Onboard AudioRealtek® ALC887 codec
High Definition Audio
2/4/5.1/7.1-channel
* To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.
Support for S/PDIF Out
Onboard LANRealtek® GbE LAN chip (10/100/1000 Mbit)
Warranty3 Years

Description :

Gigabyte GA-B250M-HD3 Motherboard

  • Supports 7th/ 6th Generation Intel® Core™ Processors
  • Dual Channel Non-ECC Unbuffered DDR4, 2 DIMMs
  • Ultra-Fast M.2 with PCIe Gen3 x4 & SATA interface
  • Intel® Optane™ Memory Ready
  • Triple display interfaces including High Definition Multimedia Interface
  • High Quality Audio Capacitors and Audio Noise Guard with LED Trace Path Lighting
  • GbE LAN with cFosSpeed Internet Accelerator Software
  • Smart Fan 5 features Multiple Temperature Sensors and Hybrid Fan Headers
  • GIGABYTE UEFI DualBIOS™
  • APP Center Including Cloud Station™ Utility

03 Years Warranty
