EKWB EK-Furious Meltemi 120 mm 1200-3500rpm Fan
  • EKWB EK-Furious Meltemi 120 mm 1200-3500rpm Fan
  • EKWB EK-Furious Meltemi 120 mm 1200-3500rpm Fan
Product | lenovo Ideapad Gaming 3 15ACH6

EKWB EK-Furious Meltemi 120 mm 1200-3500rpm Fan

Price To be announced
Status Discontinued
Product Code 15581
Brand EKWB

Key Features

  • MPN: 3831109880128
  • Model: EK-Furious Meltemi 120
  • High static pressure 120mm PC fan
  • Max Air Flow: 121 CFM = 205 m³/h
  • Maximum speed: 1200-3500 RPM (+/- 10%)
  • Noise Level: 60.9dBA
  • View More Info
Discontinued

Specification

Key Features
Noise (dBA)60.9dBA
Lifespan50.000 hrs
Operating Voltage/Power Range12V DC
Physical Specification
ColorBlack
Size120 x 120 x 38 mm

Connector 500mm long, red nylon-sleeved 4-pin PWM cable
Warranty Information
Manufacturing Warranty2 Years

Description

EKWB EK-Furious Meltemi 120 mm 1200-3500rpm Fan

The EK-Furious Meltemi 120 is the most extreme EK fan up to date. This 38mm thick extreme high-static pressure radiator cooling fan is designed purely for highest-performance computer liquid cooling systems. Developed in-house on the basis of the renowned EK-Vardar fans, they have a wide PWM range of operation and the highest speed of up to 3500 RPM. Due to a 38mm thick frame, there is space for an upgraded motor and far superior performance compared to any standard 25mm thick fan at the same RPM range.

The best possible performance of the EK-Furious Meltemi 120 fan is achieved in pull mode. Such a regime evens out the airflow through the entire surface of the radiator since the motor hub dead zone effect is lessened. The fan is equipped with a red sleeved cable just to warn off those curious little fingers from getting hurt. Seriously, 3500 RPM is no joke, and you should be extra careful around these fans if they are in operation.

EKWB EK-Furious Meltemi 120 mm 1200-3500rpm Fan

The key characteristics of EK-Furious Meltemi fans are:

High-static pressure - unlike other general-purpose computer cooling fans, the EK-Furious Meltemi fans are built specifically for computer liquid cooling systems, namely radiator cooling. The new 7 fan blade design is optimized for extremely high-pressure built upon a massive motor housed in a 38mm thick frame.

High-quality motor and bearing assembly - New electrical design, and the Dual-Ball bearing with 50.000 hours of lifespan (MTBF) @40C operation ensures uninterrupted operation for years to come. Precise Pulse Width Modulation (PWM) for fan speed adjustment allows performance adjustment on demand.

Sealed-edge fan casing - The classic, yet the effective square shape of the fan casing provides optimal performance in either pull - (suction) or push (pressure) regime without hydraulic losses, thus ensuring the optimal cooling capacity of your liquid cooling radiators. The classic shape of the fan frame also allows easy cable routing while grouping more fans on one radiator. For the best performance, EK recommends using the EK-Furious Meltemi 120ER in pull mode.

Robust design - The EK-Furious Meltemi fans fit subtly into any liquid cooling computer giving it an industrial look based on quality and performance.

Sleeved cable - It comes with a 500mm long, red nylon-sleeved 4-pin PWM cable.


Mechanical and electrical specifications of EK-Furious Meltemi fans are:

Maximum speed: 1200-3500 RPM (+/- 10%), Rated Voltage: 12V DC, Power Draw: 9.3W, PWM Duty Cycle: 35-100%, Connector: 4-pin PWM header, Shaft bearing: Dual-Ball bearing, Bearing durability: 50.000 hrs @ 40°C (MTBF), Dimensions: 120 x 120 x 38 mm


Performance characteristics of EK-Furious Meltemi fans are:

Max Air Flow: 121 CFM = 205 m³/h, Static Pressure: 7.13mm H2O = 70Pa, Sleeved cable length: 500 mm, Noise Level: 60.9dBA

The EK-Furious Meltemi fan comes with 2 Years of warranty.

What is the price of EKWB EK-Furious Meltemi 120 mm Fan in Bangladesh?

The latest price of EKWB EK-Furious Meltemi 120 mm Fan in Bangladesh is 3,300৳. You can buy the EKWB EK-Furious Meltemi 120 mm Fan at best price from our website or visit any of our showrooms.
