Dahua DHI-NVR2104HS-4KS2 4 Channel Network Video Recorders (NVR)
  • Dahua DHI-NVR2104HS-4KS2 4 Channel Network Video Recorders (NVR)
Product Page After Image | Lenovo Ideapad Flex 5

Dahua DHI-NVR2104HS-4KS2 4 Channel Network Video Recorders (NVR)

Price To be announced
Status Discontinued
Product Code 14523
Brand Dahua

Key Features

  • Model: DHI-NVR2104HS-4KS2
  • 4 IP channel max, up to 8MP resolution
  • 80Mbps record rate, H.265/H.264
  • VGA/HDMI up to 3840×2160 output
  • 1 SATA port, up to 6 TB 3.5â€� HDD
  • View More Info
local_offer
100৳ Discount
on Checkout
Discontinued

Specification

System
Main ProcessorDual-core embedded processor
Operating SystemEmbedded LINUX
Audio and Video
IP Camera Input4
Two-Way Talk1 Channel Input, 1 Channel Output, RCA
Display
Interface1 HDMI, 1 VGA
ResolutionHDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720
VGA: 1920×1080, 1280×1024, 1280×720
Decoding Capacity1ch@8MP 30fps, 4ch@1080P 30fps
Multi-Screen Display4CH: 1/4
8CH: 1/4/8/9
OSDCamera title, Time, Camera lock, Motion detection, Recording
Recording
CompressionH.265/H.264
Resolution8MP/6MP/5MP/4MP/3MP/1080P/ 720P/ D1&etc.
Record Rate80Mbps

Bit Rate16Kbps ~ 20Mbps Per Channel
Record Mode80Mbps
Record Interval1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection And Alarm
Trigger EventRecording, PTZ, Tour, Video Push, Snapshot, and Screen Tips
Video DetectionMotion Detection, MD Zones: 396 (22 × 18), and Tampering
Alarm InputN/A
Relay OutputN/A
Playback And Backup
Sync Playback1/4
Search ModeTime /Date, MD and Exact Search (accurate to second)
Playback FunctionPlay, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Shuffle, Backup Selection, Digital Zoom
Backup ModeUSB Device/Network
Third Party Support
Third Party SupportArecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, and more
Network
Interface1 RJ-45 port (10/100Mbps)
PoEN/A
Network FunctionHTTP/HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS, IP Filter, DDNS, IP Search(Support Dahua IP camera, DVR, NVS and etc.), Easy4ip
Optical Fiber InterfaceN/A
Maximum User Access128 users
Smart PhoneiPhone, iPad, Android
InteroperabilityONVIF 2.4, SDK, CGI
Storage
Internal HDD1 SATA III Port, up to 6TB capacity for each HDD
HDD ModeSingle
eSATAN/A
Auxiliary Interface
USB2 ports (1 Rear USB2.0, 1 Front USB2.0)
RS232N/A
RS485N/A
Power
Power SupplySingle, DC12V/2A
Power Consumption<3W (without HDD)
Component Environment
Operational Conditions-10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa
Storage Conditions-20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH
Construction
DimensionsCompact 1U, 260mm×224.9mm×47.6mm (10.2" x 8.9" x 1.9")
Net Weight 0.8kg (1.76 lb) (without HDD)
Gross Weight1.6kg(3.53 lb)(without HDD)
Warranty
Manufacturing Warranty01-year warranty

Description

Dahua DHI-NVR2104HS-4KS2 4 Channel Network Video Recorders (NVR)

The Dahua DHI-NVR2104HS-4KS2 4 Channel NVR comes with 4 IP channel max, up to 8MP resolution, 80Mbps record rate, H.265/H.264, VGA/HDMI up to 3840×2160 output, 4-ch synchronous playback (4x2MP max). Here 1 SATA port, up to 6 TB 3.5" HDD, 10/100M LAN ports are available. No front panel control, no Alarm I/O, 2 USB, Two-way Talk: 1/1 I/O. This NVR is also featured with 10/100M LAN No front panel control, no Alarm I/O, 2 USB, Two-way Talk: 1/1 I/O Compact 1U case, mouse included ONVIF 2.4, SDK, CGI conformance Other brands IP cameras supported: Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek and others. Free IP monitoring software available. This new NVR has 01-year warranty.

What is the price of Dahua DHI-NVR2104HS-4KS2 4 Channel NVR in Bangladesh?

The latest price of Dahua DHI-NVR2104HS-4KS2 4 Channel NVR in Bangladesh is 5,500৳. You can buy the Dahua DHI-NVR2104HS-4KS2 4 Channel NVR at best price from our website or visit any of our showrooms.

Questions (1)

Have question about this product? Get specific details about this product from expert.

Md Imdadul Haque on 11 Apr 2021

Q: Can this connect with imou ranger 2 wirelessly?

A: Yes sir, you can connect imou ranger 2 with Dahua DHI-NVR2104HS-4KS2 4 Channel Network Video Recorders (NVR).

By Star Tech Support 11 Apr 2021
