ASUS TUF GAMING Z790-PLUS WIFI DDR5 Motherboard
  • ASUS TUF GAMING Z790-PLUS WIFI DDR5 Motherboard
  • ASUS TUF GAMING Z790-PLUS WIFI DDR5 Motherboard
Product | lenovo Ideapad Gaming 3 15ACH6

ASUS TUF GAMING Z790-PLUS WIFI DDR5 Motherboard

Price To be announced
Status Out Of Stock
Product Code 27252
Brand Asus

Key Features

  • Model: TUF GAMING Z790-PLUS WIFI
  • Supported CPU: 14th Gen, 13th Gen & 12th Gen Processors (LGA1700)
  • Supported RAM: 4 x DIMM, Max. 128GB, DDR5
  • Graphics Output: 1 x DisplayPort, 1 x HDMI
  • Features: 4 x M.2 slots, Wi-Fi 6, Bluetooth v5.2
  • View More Info
Out Of Stock

Specification

Basic Information
Supported CPUIntel Socket LGA1700 for 14th Gen, 13th Gen Intel Core Processors & 12th Gen Intel Core, Pentium Gold and Celeron Processors
Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0
ChipsetIntel Z790 Chipset
BIOS192 (128+64) Mb Flash ROM, UEFI AMI BIOS
Form FactorATX Form Factor
12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
AudioRealtek S1220A 7.1 Surround Sound High Definition Audio CODEC*
- Impedance sense for front and rear headphone outputs
- Internal audio Amplifier to enhance the highest quality sound for headphone and speakers
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)
- Supports up to 32-Bit/192 kHz playback*"
Audio Features
- Audio Shielding
- Rear optical S/PDIF out port
- Premium audio capacitors
- Dedicated audio PCB layers
- Audio Cover
Expansion Slots
PCIIntel 13th & 12th Gen Processors
1 x PCIe 5.0 x16 slot
Intel Z790 Chipset
1 x PCIe 4.0 x16 slot (supports x4 mode)
1 x PCIe 4.0 x4 slot
2 x PCIe 3.0 x1 slots
Memory
TypeDDR5
Slots4 x DIMM
Supported Memory7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800 Non-ECC, Un-buffered Memory
Dual Channel Memory Architecture
Supports Intel Extreme Memory Profile (XMP)
OptiMem II
Maximum Memory128GB
Graphics
Graphics1 x DisplayPort (Supports max. 4K@60Hz as specified in DisplayPort 1.4)
1 x HDMI port (Supports 4K@60Hz as specified in HDMI 2.1)
Connector & Ports
HDMI1 x HDMI
Display Port (s)1 x DisplayPort
USB (s)Rear USB (Total 8 ports)
1 x USB 3.2 Gen 2x2 port (1 x USB Type-C)
3 x USB 3.2 Gen 2 ports (2 x Type-A + 1 x USB Type-C)
4 x USB 3.2 Gen 1 ports (4 x Type-A)
Front USB (Total 7 ports)
1 x USB 3.2 Gen 2 connector (supports USB Type-C)
1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports
2 x USB 2.0 headers support additional 4 USB 2.0 ports
LAN Port (s)1 x Intel 2.5Gb Ethernet
TUF LANGuard
Wireless Communication moduleWi-Fi 6E
2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
Supports 2.4/5/6GHz frequency band
Bluetooth v5.3
Supported StorageTotal supports 4 x M.2 slots and 4 x SATA 6Gb/s ports
Intel 13th & 12th Gen Processors
M.2_1 slot (Key M), type 2242/2260/2280/22110
- Intel 13th & 12th Gen processors support PCIe 4.0 x4 mode
Intel Z790 Chipset
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes)
4 x SATA 6Gb/s ports
RAIDIntel Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10
Audio5 x Audio jacks
Internal I/O PortsFan and Cooling related
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
4 x 4-pin Chassis Fan headers
Power related
1 x 24-pin Main Power connector
2 x 8-pin +12V Power connectors
Storage related
4 x M.2 slots (Key M)
4 x SATA 6Gb/s ports
USB
1 x USB 3.2 Gen 2 connector (supports USB Type-C)
1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports
2 x USB 2.0 headers support additional 4 USB 2.0 ports
Miscellaneous
3 x Addressable Gen 2 headers
1 x Aura RGB header
1 x Clear CMOS header
1 x COM Port header
1 x Front Panel Audio header (AAFP)
1 x 20-3 pin System Panel header with Chassis intrude function
1 x Thunderbolt (USB4) header

Back Panel I/O Ports
1 x USB 3.2 Gen 2x2 port (1 x USB Type-C)
3 x USB 3.2 Gen 2 ports (2 x Type-A + 1 x USB Type-C)
4 x USB 3.2 Gen 1 ports (4 x Type-A)
1 x DisplayPort
1 x HDMI port
1 x Wi-Fi Module
1 x Intel 2.5Gb Ethernet port
5 x Audio jacks
1 x Optical S/PDIF out port
Others
Special Features ASUS TUF PROTECTION
- DIGI+ VRM (- Digital power design with DrMOS)
- ESD Guards
- TUF LANGuard
- Overvoltage Protection
- Safeslot
- Stainless-Steel Back I/O
ASUS Q-Design
- M.2 Q-Latch
- PCIe Slot Q-Release
- Q-DIMM
- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
- Q-Slot
ASUS Thermal Solution
- M.2 heatsink
- VRM heatsink design
ASUS EZ DIY
- CPU Socket lever protector
- ProCool
- Pre-mounted I/O shield
- SafeDIMM
AURA Sync
- Aura RGB header
- Addressable Gen 2 headers
Bundled SoftwareASUS Exclusive Software
Armoury Crate
- Aura Creator
- Aura Sync
- Fan Xpert 4 (with AI Cooling II)
- Two-Way AI Noise Cancelation
- Power Saving
AI Suite 3
- TurboV EVO
- DIGI+ VRM
- PC Cleaner
TUF GAMING CPU-Z
DTS Audio Processing
MyAsus
Norton 360 for Gamers
WinRAR
UEFI BIOS
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode
Warranty Information
Manufacturing Warranty3 years

Description

ASUS TUF GAMING Z790-PLUS WIFI DDR5 Motherboard

The ASUS TUF GAMING Z790-PLUS WIFI DDR5 Motherboard adds performance and connectivity to your project. This motherboard supports 14th Generation Intel CPUs by utilizing the Intel Z790 chipset and LGA 1700 socket. Up to 128GB of DDR5 RAM may be installed across four memory slots. There are four M.2 and four SATA III connections for storage, as well as PCIe 5.0 x16, 4.0 x16, 4.0 x4, and two 3.0 x1 slots for adaptor cards. Connect to wired peripherals through two USB-A 3.2 Gen 2 and four 3.2 Gen 1 ports, or two USB-C 3.2 Gen 2x2 and four 3.2 Gen 2 ports. DisplayPort 1.4 or HDMI 2.1 interfaces are used to output video. Its RJ45 connection enables 2.5 Gigabit Ethernet, and the bundled antenna supports Wi-Fi 6E. The rear I/O panel also includes five 1/8" audio connectors and a digital audio S/PDIF output. Fans, Clear CMOS, Thunderbolt 4, RGB lighting, and front-panel USB-C 3.2 Gen 2 and USB-A 3.2 Gen 1 and 2.0 ports are all supported through internal headers. The ASUS TUF GAMING Z-790 PLUS WIFI LGA 1700 ATX Motherboard is Windows 10 and 11 64-bit compatible.

Enhanced Power Solution

The ASUS TUF GAMING Z790-PLUS WIFI DDR5 Motherboard delivers consistent power throughout the entire motherboard, preserving electrical volume whether you are performing simple chores or operating at full power during resource-demanding procedures. It is equipped with a 16+1 Phase Power DrMOS, six-layer PCB, ProCool sockets, alloy chokes, and durable capacitors that allow for stable power delivery.

Connectivity to the Core

Fast internals and accessories can be connected to via PCIe 5.0 and Thunderbolt 4 headers, as well as a front-panel USB-C 3.2 Gen 2x2 port. USB 3.2 Gen 2 doubles the speed of its predecessor, with a maximum throughput of 10 Gb/s when utilized with compatible devices, and is synonymous with USB 3.1 Gen 2.

Aura Sync RGB Effects

The ASUS TUF GAMING Z790-PLUS WIFI DDR5 14th Gen Motherboard offers an edge lighting design, addressable RGB headers, and RGB strip header support to let you set the mood for your favorite games.

Buy ASUS TUF GAMING Z790-PLUS WIFI DDR5 Motherboard from the best Motherboard Shop in BD

In Bangladesh, you can get original ASUS TUF GAMING Z790-PLUS WIFI DDR5 Motherboard From Star Tech. We have a large collection of latest ASUS Motherboard to purchase for your Desktop PC. Order Online Or Visit your Nearest Star Tech Shop to get yours at lowest price. The ASUS TUF GAMING Z790-PLUS WIFI DDR5 Motherboard comes with 3 years warranty.

What is the price of ASUS TUF GAMING Z790-PLUS WIFI DDR5 Motherboard in Bangladesh?

The latest price of ASUS TUF GAMING Z790-PLUS WIFI DDR5 Motherboard in Bangladesh is 46,500৳. You can buy the ASUS TUF GAMING Z790-PLUS WIFI DDR5 Motherboard at best price from our website or visit any of our showrooms.
