Tecnoware FGCEVDP20TT/00 20KVA Online UPS
  • Tecnoware FGCEVDP20TT/00 20KVA Online UPS
  • Tecnoware FGCEVDP20TT/00 20KVA Online UPS
Product Page After Image | Lenovo Ideapad Flex 5

Tecnoware FGCEVDP20TT/00 20KVA Online UPS

Price To be announced
Status Out Of Stock
Product Code 13363
Brand Tecnoware

Key Features

  • Model: Tecnoware FGCEVDP20TT/00
  • Dimension (WxHxD): 25 x 82.6 x 81.5cm
  • Capacity: 20 kVA
  • Power factor: 9 kW
  • Number of phases: 3Ph+N
  • View More Info
info Call for Best Price: 01313717027
Out Of Stock

Specification

Main Feature
Capacity20 kVA
Load CapacityOverload capability (On-line mode):
110% for 60 minutes, 130% for 10 minutes, >150% for 1 second
Overload capability (Battery mode):
110% for 60 minutes, 130% for 10 minutes, >150% for 1 second
Efficiency:
94%, calculated in double conversion mode at 100% load to 100% load according to standard 62040-3
Frequency (Battery Mode)50/60HZ
BatteryType: Lead acid, sealed, maintenance free
Input Features
FrequencyNominal frequency:
50/60 Hz
Input frequency range On-Line mode:
46-54 Hz o 56-64 Hz

Power Factor0.99
Input current harmonic distortion (THDi): 0.04
Voltage RangeNominal voltage:
360Vac/380Vac/400Vac/415Vac
Nominal voltage (Ph-N): 208Vac/220Vac/230Vac/240Vac
Input voltage range (Ph-N):
176Vac-276Vac to 100% load, 110Vac-300Vac to 50% load
Output Features
Voltage RangeNominal voltage:
360Vac/380Vac/400Vac/415Vac (F-N: 208Vac/220Vac/230Vac/240Vac)
Voltage Regulation (On-Line and Battery mode):
±1%
Type of WaveSinewave
Transfer Time0 ms (On-Line)
Rated power<2% (linear load) - <5% (distorting load)
Manufacture Warranty
Warranty02 Years Warranty

Description

Tecnoware FGCEVDP20TT/00 20KVA Online UPS

Tecnoware FGCEVDP20TT/00 Online UPS features with On-Line double conversion technology without transformer (VFI-SS-111), Power Factor 0.9. Here the Rectifier realized by IGBT technology with Active PFC Circuit (0.9). This UPS also Compatible with generators and EPO (Emergency Power Off). The Output voltage and frequency can be regulated from the front pane, Static and Manual Bypass. And here used Tecno Manager UPS Management Software. The UPS has 94% High Efficiency calculated in double conversion mode at 100% load, which is according to 62040-3: 2011 standard. This Online UPS also features with SINGLE-PHASE/SINGLE-PHASE 230/230 50/60Hz, POWER 20 kVA, COS 0.9, Online Double Conversion technology without transformer, DSP System, Multifunction LCD Display, Micro processor drived battery charge system, STATIC and MANUAL BYPASS, RS232 and USB, TECNOMANAGER Software.

This New Online UPS comes with 02 Years warranty.
