close| Price | 380,000৳ |
| Regular Price | 420,000৳ |
| Status | In Stock |
| Product Code | 53890 |
| Brand | Solis |
| General Information | ||
| Rated AC Output Power | 50 kW | |
| Connectivity | ||
| App Control | Yes | |
| Protection | DC reverse-polarity protection Short circuit protection Output over current protection Surge protection DC Type II / AC Type II Grid monitoring Anti-islanding protection Temperature protection Strings monitoring I/V Curve scanning Multi peak scan Integrated AFCI 2.0 Integrated DC switch Yes |
|
| Noise Level | ≤ 55 dB(A) | |
| Others | Topology: Transformerless > 150% DC/AC ratio Display: LED indicator & Bluetooth + APP |
|
| Output | ||
| AC Output | Max. output power: 50 kW Max. apparent output power: 50 kVA Rated grid voltage: 3/N/PE, 220 V / 380 V, 230 V / 400 V Rated grid frequency: 50 Hz / 60 Hz Power Factor: >0.99 (0.8 leading - 0.8 lagging) THDi: < 3% |
|
| Input (Charging) | ||
| DC Input | Max. input voltage: 1100 V Rated voltage: 600 V Start-up voltage: 180 V MPPT voltage range: 180 - 1000 V Max. input current: 4 × 42 A Max. short-circuit current: 4 × 52.5 A MPPT number / Max. input strings number: 4 / 8 |
|
| Solar Input | Yes | |
| Environment | ||
| Operating Temperature | -25°C to +60°C | |
| Physical Information | ||
| Color | White | |
| Dimension | 508 × 612 × 288 mm | |
| Weight | Approx. 35.8 kg | |
| Warranty Information | ||
| Warranty | 5 Year Warranty | |
The Solis S6-GC3P50K04-NV 50kW Three Phase ON-Grid Solar Inverter delivers efficient solar power conversion for commercial and industrial installations. With 50 kW rated AC output power and maximum efficiency of 98.6%, it supports productive solar energy generation. This Three Phase Solar Inverter features transformerless topology, advanced monitoring, and intelligent protection functions. Its design supports grid-connected solar systems requiring consistent power conversion and effective system management.
Featuring a maximum efficiency of 98.6%, the Solis S6-GC3P50K04-NV helps convert DC electricity into usable AC power. Its maximum input voltage reaches 1100V DC, with a rated input voltage of 600V. The MPPT voltage range spans 180–1000V, supporting flexible solar array configurations. Additionally, its DC/AC ratio exceeds 150%, allowing greater solar panel capacity relative to inverter output.
The Solis S6-GC3P50K04-NV operates with three-phase grid connections rated at 220/380V or 230/400V. It supports both 50Hz and 60Hz grid frequencies. The inverter delivers a power factor above 0.99, adjustable between 0.8 leading and 0.8 lagging. With total harmonic distortion below 3%, this 50 kW Solar Inverter supports controlled AC power delivery for commercial installations.
For enhanced operational protection, the Solis S6-GC3P50K04-NV incorporates DC reverse-polarity, short-circuit, output overcurrent, and surge protection. Type II DC and AC surge protection helps guard against electrical transients. Additional features include anti-islanding protection, temperature monitoring, integrated AFCI 2.0, and a built-in DC switch. String monitoring, I/V curve scanning, and multi-peak scanning support solar system diagnostics.
The Solis S6-GC3P50K04-NV offers Bluetooth connectivity, app control, and LED indicators for convenient system monitoring. Its IP66-rated enclosure supports installation in demanding outdoor environments. Measuring 508 × 612 × 288 mm and weighing approximately 35.8 kg, this inverter suits space-conscious installations. Operating temperatures range from -25°C to +60°C, while noise levels remain at or below 55 dB(A).
The Solis S6-GC3P50K04-NV is designed primarily for grid-connected commercial and industrial solar installations. Its advanced monitoring and protection functions support efficient solar generation and system oversight. Although an energy storage solar inverter may support battery charging, this model is specified as an ON-Grid solar inverter. Battery compatibility should be confirmed separately before planning an energy storage system.
In Bangladesh, you can get original Solis S6-GC3P50K04-NV 50kW Solar Inverter From Star Tech. We have a large collection of latest Inverter to purchase. Order Online Or Visit your Nearest Star Tech Shop to get yours at lowest price. The Solis S6-GC3P50K04-NV 50kW Solar Inverter comes with 5 Year warranty.
The latest price of Solis S6-GC3P50K04-NV 50kW Solar Inverter in Bangladesh is 380,000৳. You can buy the Solis S6-GC3P50K04-NV 50kW Solar Inverter at best price from our website or visit any of our showrooms.
