close| Price | To be announced |
| Status | Up Coming |
| Product Code | 50450 |
| Brand | MSI |
| Basic Information | ||
| Supported CPU | Supports Intel Core Ultra Processors (Series 2) LGA 1851 |
|
| Chipset | Intel H810 | |
| BIOS | Flash BIOS Button | |
| Form Factor | Micro-ATX | |
| Audio | Realtek ALC897 Codec 7.1-Channel High Definition Audio |
|
| Expansion Slots | ||
| PCI | 1x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset) |
|
| M.2 Socket | 1x M.2 | |
| Memory | ||
| Type | DDR5 | |
| Slots | 2 x UDIMM | |
| Maximum Memory | 128GB | |
| Graphics | ||
| Graphics | 1x HDMI Support HDMI 2.1, maximum resolution of 4K 60Hz* 1x DisplayPort Support DisplayPort 1.4, maximum resolution of 4K 60Hz* *Available only on processors featuring integrated graphics |
|
| Connector & Ports | ||
| HDMI | 1x HDMI 2.1 | |
| Display Port (s) | 1 x DisplayPort 1.4 | |
| USB (s) | 4x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 5Gbps Type A (Rear) 2x USB 5Gbps Type A (Front) 1x USB 5Gbps Type C (Front) |
|
| LAN Port (s) | Realtek 8125D 2.5Gbps LAN | |
| Supported Storage | 1x M.2 M.2_1 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 4x SATA 6G |
|
| Internal I/O Ports | 1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 2x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 5Gbps Type A ports 1x USB 5Gbps Type C ports |
|
| TPM (Trusted Platform Module ) | 1x TPM pin header(Support TPM 2.0) | |
| Others | ||
| Special Features | 4x EZ Debug LED 1x EZ Memory Detection LED |
|
| Warranty Information | ||
| Manufacturing Warranty | 3 Years Warranty | |
The MSI PRO H810M-E DDR5 LGA1851 mATX Motherboard is built for stability, speed, and compatibility, making it a strong foundation for modern PC builds. Powered by the Intel H810 chipset, this MSI PRO H810M-E DDR5 Motherboard supports Intel Core Ultra Series 2 processors on the LGA1851 socket, ensuring reliable performance for productivity and everyday computing. Compact in design, the MSI PRO H810M-E micro atx Motherboard is engineered to deliver efficiency without compromising on essential features.
The MSI PRO H810M-E DDR5 Motherboard supports up to 128GB DDR5 memory with speeds ranging from 4800 MT/s to 6400 MT/s, depending on CPU and configuration. With dual-channel architecture, non-ECC unbuffered memory, and CUDIMM support, it ensures smooth multitasking and dependable performance. Expansion options include one PCIe 5.0 x16 slot for graphics cards and one PCIe 4.0 x1 slot for additional devices, making this MSI 810 Motherboard versatile for upgrades and customization.
The MSI PRO H810M-E micro atx Motherboard offers HDMI 2.1 and DisplayPort 1.4 outputs supporting 4K at 60Hz, multiple USB 2.0 and USB 5Gbps ports including Type-C, and Realtek 8125D 2.5Gbps LAN for fast networking. Storage options include one PCIe 4.0 M.2 slot and four SATA 6Gb/s ports, while audio is powered by the Realtek ALC897 codec with 7.1-channel HD sound. With EZ Debug LEDs, TPM 2.0 support, and robust internal I/O, the MSI PRO H810M-E DDR5 Motherboard delivers secure, efficient, and reliable performance for modern PC builds.
In Bangladesh, you can get original MSI PRO H810M-E DDR5 LGA1851 mATX Motherboard From Star Tech. We have a large collection of latest MSI Motherboard to purchase for your Desktop. Order Online Or Visit your Nearest Star Tech Shop to get yours at lowest price. The MSI PRO H810M-E DDR5 LGA1851 mATX Motherboard has 3 year warranty.
The latest price of MSI PRO H810M-E Motherboard in Bangladesh is 0৳. You can buy the MSI PRO H810M-E Motherboard at best price from our website or visit any of our showrooms.
