| Price | To be announced |
| Status | Up Coming |
| Product Code | 45706 |
| Brand | MSI |
| Basic Information | ||
| Supported CPU | Supports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors Socket AM5 |
|
| Chipset | AMD B850 | |
| BIOS | Flash BIOS Button | |
| Form Factor | mATX 243.84mmx243.84mm |
|
| Audio | Realtek ALC897 7.1-Channel High Definition Audio |
|
| Expansion Slots | ||
| PCI | 2x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) PCI_E1 slot • Supports PCIe 5.0 x16 (For Ryzen™ 9000/ 7000 Series processors) • Supports PCIe 4.0 x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors) • Supports PCIe 4.0 x4 (For Ryzen™ 8500/ 8300 Series processor) |
|
| M.2 Socket | 2x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 4x SATA 6G M2_1 slot • Supports up to PCIe 5.0 x4 (For Ryzen 9000/ 7000 Series processors) • Supports up to PCIe 4.0 x4 (For Ryzen 8000 Series processors) M2_2 slot • Supports up to PCIe 4.0 x4 (For Ryzen 9000/ 8700/ 8600/ 8400/ 7000 Series processors) • Supports up to PCIe 4.0 x2 (For Ryzen 8500/ 8300 Series processors) |
|
| Memory | ||
| Type | DDR5 | |
| Slots | 4 x UDIMM | |
| Supported Memory | Memory Support DDR5 8200 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s Ryzen™ 9000 Series Processors max. overclocking frequency: • 1DPC 1R Max speed up to 8200+ MT/s • 1DPC 2R Max speed up to 6400+ MT/s • 2DPC 1R Max speed up to 6400+ MT/s • 2DPC 2R Max speed up to 6000+ MT/s Supports AMD POR Speed and JEDEC Speed Supports Memory Overclocking and AMD EXPOTM Supports Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM, Clock Driver bypass mode only* |
|
| Maximum Memory | 256GB | |
| Graphics | ||
| Graphics | 1x HDMI Support HDMI 2.1, maximum resolution of 4K 60Hz 1x DisplayPort Support DisplayPort 1.4, maximum resolution of 4K 60Hz |
|
| Connector & Ports | ||
| HDMI | 1x HDMI 2.1 | |
| Display Port (s) | 1x DisplayPort 1.4 | |
| USB (s) | 4x USB 2.0 (Front) 3x USB 5Gbps Type A (Rear) 2x USB 5Gbps Type A (Front) 3x USB 10Gbps Type A (Rear) 2x USB 10Gbps Type C (Rear) 1x USB 10Gbps Type C (Front) |
|
| LAN Port (s) | Realtek 8126 5G LAN | |
| Wireless Communication module | Wi-Fi 7 Solution The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz (160MHz) up to 2.9Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be Supports Bluetooth 5.4, MLO, 4KQAM |
|
| Supported Storage | 2x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 4x SATA 6G M2_1 slot • Supports up to PCIe 5.0 x4 (For Ryzen 9000/ 7000 Series processors) • Supports up to PCIe 4.0 x4 (For Ryzen 8000 Series processors) M2_2 slot • Supports up to PCIe 4.0 x4 (For Ryzen 9000/ 8700/ 8600/ 8400/ 7000 Series processors) • Supports up to PCIe 4.0 x2 (For Ryzen 8500/ 8300 Series processors) |
|
| RAID | Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices Supports RAID 0 and RAID 1 for M.2 NVMe storage devices |
|
| Audio | 1x Front Audio (JAUD) | |
| Internal I/O Ports | 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x Power Connector(PCIE_PWR 8pin) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 3x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 5Gbps Type A ports 1x USB 10Gbps Type C ports |
|
| TPM (Trusted Platform Module ) | 1x TPM pin header(Support TPM 2.0) |
|
| Others | ||
| Special Features | 4x EZ Debug LED 1x EZ Memory Detection LED |
|
| Bundled Software | Support for Windows 11 64-bit | |
| Warranty Information | ||
| Manufacturing Warranty | 3 Years Warranty | |
The MSI B850M GAMING PLUS WIFI AM5 mATX Motherboard represents a robust solution designed for gaming enthusiasts, content creators, and users who demand high performance with modern connectivity and dependable operation. Built upon the AMD B850 chipset and AM5 socket foundation, this micro-ATX form factor board accommodates the newest AMD Ryzen 9000, 8000, and 7000 Series desktop processors, providing advanced performance capabilities and forward-looking compatibility. The MSI B850M motherboard supports memory configurations up to 256GB using DDR5 technology across four UDIMM slots, enabling users to achieve exceptional speeds reaching 8200+ MT/s when overclocked, with particular optimization for Ryzen 9000 Series processors. The design incorporates dual-channel memory architecture, AMD EXPO compatibility, and sophisticated overclocking features, positioning it as an excellent choice for demanding computing tasks and gaming applications. Display connectivity options encompass HDMI 2.1 and DisplayPort 1.4 outputs, each capable of delivering 4K resolution at 60Hz refresh rates, providing exceptional visual quality when used with processors that include integrated graphics capabilities. System expansion opportunities include two PCIe x16 slots alongside one PCIe x1 slot, incorporating Gen 5.0 compatibility for premium graphics cards and Gen 4.0/3.0 support for diverse expansion components. Storage capabilities offer exceptional versatility through dual M.2 connections supporting PCIe 5.0/4.0 standards and four SATA 6Gb/s connections, with RAID configuration options including 0/1/10 for SATA devices and 0/1 for NVMe storage solutions. Audio functionality utilizes the Realtek ALC897 processor, providing 7.1-channel high-definition sound output for superior gaming and multimedia experiences. Network connectivity features forward-thinking technology with Realtek 8126 5G LAN capability and built-in Wi-Fi 7 (802.11be) support, incorporating MU-MIMO technology, tri-band operation across 2.4GHz/5GHz/6GHz frequencies, and Bluetooth 5.4 for exceptional wireless connectivity performance. The MSI B850M GAMING PLUS WIFI incorporates comprehensive internal connectivity, including multiple fan connection points, RGB lighting connectors (JARGB_V2 and JRGB), TPM 2.0 compatibility, and extensive USB port selection featuring USB 10Gbps Type-C and Type-A connections on front and rear interfaces. System diagnostics and monitoring capabilities include 4x EZ Debug LEDs and an EZ Memory Detection LED for simplified troubleshooting and system status verification. Optimized for Windows 11 64-bit operating systems, the MSI B850M GAMING PLUS WIFI serves as an ideal solution for users requiring high-performance computing capabilities.
In Bangladesh, you can get original MSI B850M GAMING PLUS WIFI AM5 mATX Motherboard From Star Tech. We have a large collection of latest MSI Motherboard to purchase for your Desktop. Order Online Or Visit your Nearest Star Tech Shop to get yours at lowest price.The MSI B850M GAMING PLUS WIFI AM5 mATX Motherboard has 3 year warranty.
The latest price of MSI B850M GAMING PLUS WIFI mATX Motherboard in Bangladesh is 0৳. You can buy the MSI B850M GAMING PLUS WIFI mATX Motherboard at best price from our website or visit any of our showrooms.
