Must LP16-24100 25.6V 100Ah UPS Battery
  • View of the Must LP16-24100 UPS Battery showing power terminals, LED indicators, comm ports, and WiFi antenna.
Product Page after image | Rajshahi gazipur Offer

Must LP16-24100 25.6V 100Ah UPS Battery

Price To be announced
Status Up Coming
Product Code 46029
Brand Must

Key Features

  • Model: LP16-24100
  • Nominal Voltage: 25.6V
  • Nominal Capacity: 100Ah/ 2560Wh
  • Life Cycles: 6000 cycles @ 80% DOD, 25°C
  • Wall-mounted, Stacked, or Rack-mounted
  • View More Info
Up Coming

Specification

General Information
TypeLiFePO4 Battery
Capacity100Ah/ 2560Wh
Input Voltage25.6V
Max. Charging Current100A
Max. Discharge Current100A
Operating TemperatureCharge: 0℃ ~50℃
Discharging: -20℃ ~60℃
Storage: -5~35°C
OthersSafety Function: Over-charge, Over-discharge, Over-current, Low/High-temperature, Short-circuit Protections
Module Parallel: Up to 40 units
Communication: CAN2.0/RS232/RS485
IP Protection level: IP21
Installation Mode: Wall-mounted, Stacked-mounted, Rack-mounted(optional)
Long lifespan: 6000+ cycles @ 80% DOD, 25°C
Ideal For: Residential solar ESS, Commercial backup systems, Off-grid power stations, Modular rack systems and hybrid inverter setups
Physical Information
MaterialSPCC
Dimension442*485.5*177mm
Weight27 kg
Warranty Information
Warranty1 Years

Description

Must LP16-24100 25.6V 100Ah UPS Battery

The Must LP16-24100 25.6V 100Ah UPS Battery is a high-capacity lithium power source. Designed to provide high performance, a long lifespan, and exceptional dependability in modern power systems. This Must LP16-24100 25.6V 100Ah UPS Battery is designed with superior lithium iron phosphate (LiFePO4) technology for safety, stability, and efficiency, making it excellent for domestic solar systems, business energy storage, and backup power applications. With a nominal voltage of 25.6V and a capacity of 100Ah, it provides 2560Wh of clean energy at a maximum output power of 2.5KW. The battery is designed for endurance, with over 6000 cycles at 80% depth of discharge (DOD) at 25°C, ensuring long-term value and constant performance for years. The Must LP16-24100 25.6V UPS Battery supports a variety of installation modes, including wall-mounted, stacked, and rack-mounted configurations, allowing users to create efficient energy storage systems that are specific to their requirements. Its modular architecture enables for the parallel connection of up to 40 units, effortlessly extending total capacity. This Must LP16-24100 UPS Battery comes with a sophisticated WiFi-enabled Battery Management System (BMS) with an LCD display that provides real-time monitoring and protection against overcharge, over-discharge, over-current, short circuits, and temperature changes. It also supports the CAN2.0, RS232, and RS485 communication protocols, ensuring interoperability with hybrid inverters and advanced energy management solutions. The Must LP16-24100 100Ah UPS Battery is designed for adaptability and performance, with a rugged SPCC steel casing and an IP21 protection grade that ensures long-lasting durability and heat resistance. It operates optimally throughout a wide temperature range, charging from 0°C to 50°C and discharging from -20°C to 60°C. The suggested charge voltage is 29.2V, with a discharge cutoff of 22V, to ensure safe and efficient energy consumption. This Must Battery for UPS provides outstanding reliability with little maintenance, making it suitable for applications such as domestic solar ESS, commercial backup power, and off-grid systems.

Buy Must LP16-24100 25.6V 100Ah UPS Battery from Star Tech

In Bangladesh, you can get original Must LP16-24100 25.6V 100Ah UPS Battery From Star Tech. We have a large collection of latest Must UPS Battery to purchase for Your UPS. Order Online Or Visit your Nearest Star Tech Shop to get yours at lowest price. The Must LP16-24100 25.6V 100Ah UPS Battery comes with 1 year warranty.

What is the price of Must LP16-24100 25.6V UPS Battery in Bangladesh?

The latest price of Must LP16-24100 25.6V UPS Battery in Bangladesh is 0৳. You can buy the Must LP16-24100 25.6V UPS Battery at best price from our website or visit any of our showrooms.
